    SmartlockPro AGTR2-W Receptacle/Outlet, 125 VAC, 20 A, NEMA: NEMA 5-20R, AFCI/GFCI Socket, Back, Side Wiring, White

    SmartlockPro AGTR2-W

    The SmartlockPro® dual-function AFCI/GFCI receptacle offers protection both from electrical fires that could result from arc-faults and from electrical shock due to ground faults in one smart device. Through advanced technology, the SmartlockPro dual-function AFCI/GFCI receptacle helps protect home and family by working to detect arc-fault and ground fault hazards and, if detected, quickly cuts off power to help avoid a potential fire or shock occurrence. The SmartlockPro dual-function AFCI/GFCI receptacle offers a National Electrical Code® (NEC®) Compliant option for AFCI/GFCI protection in residential kitchens and laundry areas for new construction, modifications/extensions and replacement receptacles. It is also ideal as a replacement for ungrounded receptacles, satisfying NEC requirements for both AFCI and GFCI protection.

    Type Dual-Function
    Voltage Rating 125 VAC
    Current Rating 20 A
    Number of Poles 2
    Socket Type AFCI/GFCI
    Grounding Type Self-Grounding
    Number of Wires 3
    Wire Size 14 to 10 AWG
    Wiring Type Back, Side
    NEMA Rating NEMA 5-20R
    Operating Temperature -35 to 66 deg C
    Material Polycarbonate
    Color White
    Includes Wallplate/Faceplate, Screws, Self-Grounding Clip
    • Trip threshold meets or exceeds UL requirements for tripping time on ground faults and on both series and parallel arcs for optimal safety
    • Engineered to meet the latest UL standard for auto-monitoring (self-test), periodically conducts an automatic internal test to confirm that GFCI protected power is available
    • On initial power up, tests the GFCI circuit within 3 s
    • Patented lockout action prevents reset if the device is damaged
    • Status indicator light provides simple, intuitive feedback on power and protection status as well as indication of line/load reversal for at-a-glance analysis
    • Test and reset buttons are readily accessible on the face of the device
    • Improved immunity to high frequency noise reduces nuisance tripping
    • Superior-resistance to electrical surges and over-voltages enhancing reliability
    • Patented bridge contact design provides individual sets of contacts for receptacle face and downstream receptacles, no power will be delivered to receptacle face if improperly wired (line-load reversed)
    • One piece T design trip latch mechanism provides efficient operation
